1/250,000 Resolution Electronic Carton / Computer Servo Box Compressive Tester
Product Description:
Compression strength tester main for box ,paperbox ,corrugated box,carton...to test the pressure resistance and strike endurance during transportation or carry.
Technical characters:
1.Test items: Compression Test, Stacking Test and Press Standard Test
2.Adopt advanced accurate sensor and foreign high capable motor, unite advanced measurement and control technology to get speed accuracy and precision measurement.
3.Gentle mechanical transmission, multi-level security protection function.
4.Touch screen display, show its dynamic curves, print out quietly.
Application industry:
Home appliances, computers, mobile phones, electronic products, washing machines, shoes, food, medicine, furniture and other industries need to carton packaging, such as corrugated box packaging, honeycomb boxes and so on. At the same time can also be used in plastic barrels (edible oil, mineral water), paper barrels, cartons, paper cans, container barrels (IBC barrels)
Application standard:
TAPPI-T804,JIS-20212,GB4857.3.4,
ASTM-D642, QB/T1048, BS EN ISO 12048,
GB/T4857.16, GB/T8167, GB/T8168, GB/T4857.3,
GB/T4857.4
Techincal parameter:
| Capacity | 1000,2000,5000kg |
| Resolution | 1/250,000 |
| Unit | kg,lb,n,g switchable |
| Test space | 100×100×100cm(it customizes by customer) |
| Drive System | servo system,precision ball screw, DC variable speed drive system |
| Test speed | 0.5~1000mm/min, keyboard inputing |
| Dimension | 170×100×185cm |
| Weight | 550kg |
| Power | 1φ,220V/50Hz |
| Safety Device | Stroke protection,Force and Elongation protection,Emergency stop device,Sensing device when specimen is destroyed. |
Features of Computer Servo Box Compressive Tester :
1.Using a single-screen operation; do not need to switch the screen;
2.With three languages in Simplified Chinese, Traditional Chinese and English, the software interface can be switched easily;
3.Adopting windows platform, and all the parameter settings can be processed in the dialog box, and it operates easily;
4.The pattern of Test reports can be self-designated; test data can be displayed directly in the main screen;
5.Choosing translational, comparative mode at the same time to make a number of curve data comparison;
6.With a variety of measurement units, Measure In Imperial & Metric are switchable;
